- Condition:New
- Warranty:6 months
- Applicable Industries:Energy & Mining
- Local Service Location:UNITED KINGDOM
- Local Service Location:United States
- Showroom Location:UNITED KINGDOM
- Showroom Location:United States
- Place of Origin:CN;HEB
- Type:DRILL BIT
- Machine Type:Drilling Tool
- Certification:API
- Material:CARBIDE
- Processing Type:forging
- Use:Well Drilling
- Brand Name:EAST
- Product Name:Carbide Steel Material and Drilling Tool Machine Type 6 inch PDC Bit
- Diameter:6"= 152 mm
- Body:Matrix Body
- Blades Qty:5
- Model:M223
- Pin Thread:API Reg. 3 1/2"
- Cutter Size:16/13 mm
- MOQ:1 Piece
- Application:Oilfield Drilling
- Advantage:High Performance
Carbide Steel Material and Drilling Tool Machine Type 6 inch PDC Bit
G series PDC drill bit size range 4 1/2 inch to 17 inch, IADC: from M123 to M433.
1. Product Size: 6"= 152mm
2. Model: G1655
3.IADC: M223
4. Body: Matrix
Bit Specification | Carbide Steel Material and Drilling Tool Machine Type 6 inch PDC Bit | ||||
Total Cutters | 24 | ||||
Blades | 5 | ||||
Cutter Size | 16/13mm | ||||
Nozzles Qty | 7NZ | ||||
Junk Slot Area | 7.5 in2 | ||||
Gauge Length | 1.5 in | ||||
Make Up Length | 8.5in | ||||
Connection | API Reg. 3 1/2" | ||||
Cangzhou East Drilling Tools Co.,Ltd is a China professional manufacturer of tricone bit,PDC bit,hole opener ,drag bit inOil&Gas,Mining and Water Well Drillingfields.
Our company has worked on production and exporting business more than 10 years and have exported to America,UK,Canada,Italy,Dubai,Singapore,Brazil,South Africa and so on.
We have professional team to offer good quality drilling bits and also can provid creative solutions for you. So welcome to visit us !
Packing
Steel box is the most popular packing for tricone bit,we also accpet special packing reqirement before shipment or production.For example ,Carton Box Design with your company name.
Delivery
Usually we have enough stock for the normal size of tricone bits ,so the delivery time will be 2-3 work days,we need this time to paint and packing.If we dont have stock or stock is not enough,we will need 7-15 work days to produce as your requirement.
